SIMSCAN

  • SIMSCAN-E
  • SIMSCAN 30
  • SIMSCAN 22
  • Upto 63 blue triple-cross lasers for ultra-fast scanning
  • Upto 17 blue parallel lasers for hyperfine scanning
  • 1 extra blue laser for deep hole scanning
  • Sample Part Scanned with SIMSCAN

    For more samples:
    See it in action:

    See it in Action

    For more videos:

    Massive Scanning Area

    Up to 700 × 600 mm
    (Up to 27.5 × 23.6 in)

    Metrology-grade Accuracy

    0.020 mm
    (0.0008 in)

    Nature

    Precise Volumetric Accuracy

    0.035 mm/m
    (0.00042 in/ft)

    Clean Detailed Resolution

    Up to 0.020 mm
    (Up to 0.0008 in)

    Laser Scanning Modes

    Ultra-fast Scanning

    Upto 63 Blue Cross Laser Mode

    For Ultra-fast Scanning

    Hyperfine Scanning

    Upto 17 Blue Parallel Laser Mode

    For Hyperfine Scanning

    Deep Hole Scanning

    +1 Extra Blue Laser Mode

    For Deep Hole Scanning

    Unbeatable Scanning Rate

    Upto 6,300,000 measurements/s

    Outstanding Depth of Field

    550 mm
    (21.7 in)

    Novel Laser Technology

    Upto 81 laser lines in total

    High Surface Adaptability

    Reflective and black surfaces

    Design and Aesthetics

    Features

    Wireless 3D Scanning

    The first wireless handheld laser 3D scanner in the market

    The SIMSCAN-E is the first handheld scanner in the SIMSCAN series that is equipped with a wireless module. The wireless module allows the SIMSCAN-E to transform into a fully cable-free 3D scanner. With its advanced edge computing capabilities and high-definition industrial cameras, it can capture 3D data with remarkable precision and efficiency at speeds up to 6.3 million measurements/s.

    The wireless module is equipped with a high capacity dual-cycle power supply that allows the SIMSCAN-E to scan for long periods without needing a physical power supply. This versatility allows it to handle a wide range of tasks effortlessly.

    HD Mode
    Scan the object

    Data Capture in Narrow Spaces

    Compared with its competitors, SIMSCAN has a much shorter camera distance of 130 mm, which forms a steeper viewing angle allowing for the scanner to see in narrow spaces. This makes SIMSCAN, combined with it compact size, a more capable scanner for capturing accurate and complete data in hard-to-reach areas like deep grooves and confined areas.

    Scan the object

    Industry leading Accuracy

    With powerful hardware and software, SIMSCAN delivers metrology-grade high-precision measurements. With its built-in HD cameras and three scanning modes, it realizes high-precision scanning with an accuracy up to 0.020 mm. This combination of enhancements allows highly accurate capture of 3D data of objects in confined areas with complex surfaces.

    Triple cross laser technology

    The new SIMSCAN-E incorporates Scantech’s all new Triple Cross Laser technology. The triple cross technology is a step up from the industry standard double cross technology. It employs lasers arranged in cross to form a diamond shaped grid pattern. This substantially increases the rate at which data is captured. The triple cross technology has a total of 63 blue laser lines capturing data at an astonishing rate of 6.3 million measurements/s.

    Additionally, the parallel blue laser mode used for hyperfine scanning has been upgraded to use a total of 17 blue lasers.

    HD Mode

    Industrial Grade Protection

    Compact and secure storage

    All Scantech products are packaged in industrial grade cases to assure that all components are stored securely and to make sure that no damage is caused during transportation.

    In addition, the smart design of the protective case ensures that all components needed for the operation of the system can be accessed quickly.

    HD Mode

    Photogrammetry System using MSCAN-L15

    Optional Accessories

    AIRGO Power

    AIRGO POWER

    • Portable replacement for a PC
    • Integrated battery power
    • Wireless PC transmission

    Learn More
    Research and Analysis

    MSCAN-L15

    • Unique HDR mode
    • High volumetric accuracy
    • Blue LEDs for higher accuracy

    More Images

    AirGO Power

    AirGO Power, is a new generation of smart wireless communication link, specially designed for mobile 3D scanning. In areas with no power supply, two exchangeable batteries provide an uninterruptible power supply. It has the capability to transform traditional 3D scanning methods by removing the need for a dedicated PC and long cables, allowing for true wireless 3D scanning.
    AirGO Power is compatible with all Scantech metrology-grade handheld scanners. Its onboard processor can compute and store massive scanned data, which can be transferred to a computer via Wi-Fi 6. With the help of projecting software and AR glasses, users can monitor the scanning progress in real time.

    MSCAN-L15

    The MSCAN-L15 photogrammetry system is tailored to deliver high-precision geometric measurements of large-scale workpieces. When used in conjunction with any Scantech 3D scanner, the volumetric accuracy can be greatly increased.
    The unique HDR mode of the MSCAN-L15 allows for great adaptability in various environments, while the use of blue LED lights increase the accuracy of the data. With a large scanning area and a long depth of field, the MSCAN-L15 can capture point data of large-scale projects and parts at a volumetric accuracy of 0.015 mm/m. It is a great tool for obtaining 3D data of deformed surfaces and generate intuitive deviation values.
    Research and Analysis

    SCANTECH Customers Around the Globe

    SIMSCAN Specifications

    SIMSCAN-E SIMSCAN 30 SIMSCAN 22
    Scan Mode Ultrafast Scanning 63 blue laser lines
    (Triple Cross Technology)
    22 blue laser lines
    (Double Cross Technology)
    14 blue laser lines
    (Double Cross Technology)
    Hyperfine Scanning 17 blue parallel laser lines 7 blue parallel laser lines
    Deep Hole Scanning 1 extra blue laser line
    Total Laser Lines 81 30 22
    Accuracy 0.020 mm
    (0.0008 in)
    Volumetric Accuracy Standalone 0.015 mm + 0.035 mm/m
    (0.0006 in + 0.0014 in/ft)
    With MSCAN-L15 0.015 mm + 0.012 mm/m
    (0.0006 in + 0.0005 in/ft)
    Resolution Up to 0.020 mm
    (Up to 0.0008 in)
    Scanning Rate Up to 6,300,000 measurements/s Up to 2,020,000 measurements/s Up to 1,250,000 measurements/s
    Stand-off Distance 300 mm
    (11.8 in)
    Scanning Area 700 mm × 600 mm
    (27.6 in × 23.6 in)
    650 mm × 550 mm
    (25.6 in × 21.7 in)
    Depth of Field 550 mm
    (21.7 in)
    Laser Class CLASS II (eye-safe)
    Software DefinSight Scanviewer
    Output Formats .stl, .obj, .ply, .asc, .igs, .txt, .mk2, .umk and etc.
    Operating Temperature -10°C – 40°C
    (14°F – 104°F)
    Interface Mode USB 3.0
    Wireless Module Included Not Compatible
    Weight 600 g
    (1.3 lb)
    570 g
    (1.2 lb)
    Dimensions 203 mm × 80 mm × 44 mm
    (8 in × 3.1 in × 1.7 in)
    Patents CN204329903U, CN104501740B, CN104165600B, CN204988183U, CN204854633U, CN204944431U, CN204902788U, CN105068384B, CN105049664B, CN204902784U, CN204963812U, CN204902785U, CN204902790U, CN106403845B, CN209197685U, CN209263911U, CN106500627B, CN106500628B, CN206132003U, CN206905709U, CN107202554B, CN209310754U, CN209485295U, CN209485271U, CN305446920S, CN209991946U, US10309770B2, KR102096806B1,US10914576B2, EP3392831A4
    Optional Accessories
    Portable CMM K-Probe Single Point Repeatability 0.030 mm
    (0.001 in)
    Tracking Frequency 60 Hz

    SIMSCAN Specifications

    SIMSCAN-E SIMSCAN 30 SIMSCAN 22
    Scan Mode
    Ultrafast Scanning 63 blue laser lines
    (Triple Cross Technology)
    22 blue laser lines
    (Double Cross Technology)
    14 blue laser lines
    (Double Cross Technology)
    Hyperfine Scanning 17 blue parallel laser lines 7 blue parallel laser lines
    Deep Hole Scanning 1 extra blue laser line
    Total Laser Lines 81 30 22
    Accuracy 0.020 mm
    (0.0008 in)
    Volumetric Accuracy
    Standalone 0.015 mm + 0.035 mm/m
    (0.0006 in + 0.0014 in/ft)
    With MSCAN-L15 0.015 mm + 0.012 mm/m
    (0.0006 in + 0.0005 in/ft)
    Resolution Up to 0.020 mm
    (Up to 0.0008 in)
    Scanning Rate Up to 6,300,000 measurements/s Up to 2,020,000 measurements/s Up to 1,250,000 measurements/s
    Stand-off Distance 300 mm
    (11.8 in)
    Scanning Area 700 mm × 600 mm
    (27.6 in × 23.6 in)
    650 mm × 550 mm
    (25.6 in × 21.7 in)
    Depth of Field 550 mm
    (21.7 in)
    Laser Class CLASS II (eye-safe)
    Software DefinSight Scanviewer
    Output Formats .stl, .ply, .obj, .igs, .stp, .wrl, .xyz, .dae, .fbx, .ma, .asc or customized
    Operating Temperature -10°C – 40°C
    (14°F – 104°F)
    Interface Mode USB 3.0
    Wireless Module Included Not Compatible
    Weight 600 g
    (1.3 lb)
    570 g
    (1.2 lb)
    Dimensions 203 mm × 80 mm × 44 mm
    (8 in × 3.1 in × 1.7 in)
    Patents CN204329903U, CN104501740B, CN204854633U, CN204944431U, CN204902788U, CN105068384B, CN105049664B, CN204902784U, CN204902785U, CN106403845B, CN110030946B, CN111833392A, CN212300269U, CN211904059U, CN211696268U, CN306053019S, CN212606697U, CN111932465A, CN111694665A, CN306321502S, EP3392831A4
    Optional Accessories
    Portable CMM K-Probe
    Single Point Repeatability 0.030 mm
    (0.001 in)
    Tracking Frequency 60 Hz

    Got a Question About the SIMSCAN 3D Scanner?

    The SIMSCAN is ideal for scanning objects the size of a coin to medium sized object like engines and sculptures.

    The SIMSCAN and the KSCAN-Magic both use blue lasers to scan objects at the metrology-grade level. The difference between the two scanners is that the SIMSCAN does not have the infrared laser for large area scanning and the in-built photogrammetry system.

    However, the SIMSCAN differentiates itself by its compact and ergonomic design, a longer depth of field, and a faster scanning rate, resulting in its ability to scan objects in tight and narrow spaces.

    The three scanning modes on the SIMSCAN differ in the number and configuration of the lasers. Basically, the higher laser count equates to faster scanning speeds while taking a small dip in accuracy and resolution. However, the scanning modes can be flexibly switched and combined to satisfy different application needs while satisfying the metrology-grade accuracy required for an efficient workflow.

    The MSCAN-L15 can help increase the volumetric accuracy by using photogrammetry to capture the position of the markers. Marker positions captured by a photogrammetry system have a higher accuracy which results in better volumetric accuracy when scanning medium sized objects.
