Brilliant texture
The Ray II’s 36 MP 3-camera system can detect even the smallest surface irregularities with exceptional HDR texture.
Lifelike replicas
Recreate every detail in true-to-life color for heritage preservation.
Scan for critical evidence
Enhanced color accuracy in forensic applications helps identify crucial evidence such as bloodstains.
Auto Calibration
The Ray II has the ability to automatically calibrate itself by scanning the surroundings, or let you know if further action is required.
Certified Accuracy
Scan with full confidence knowing that your scanner has been verified to fall within specifications.
Declared conformity
Your scanner has been rigorously tested and is guaranteed to conform to the required list of 11 European safety standards.
Industry leading long-range capture
The Artec Ray II has an expansive 360°-300° field of view that gives you flexibility to capture objects from 0.5 to 130 meters away with high accuracy and superior quality.
Real-time registration on board
Track the scanner’s movement in real time with feature tracking and advanced algorithms for intuitive 3D-space navigation including Ray II’s Visual Inertial System (VIS), Altimeter, compass, and Global Navigation Satellite System.
Onboard control
Fuss-free scanning is ensured with the intuitive Ray II – with basic features accessible on board, it’s as simple as pressing a button, with no computer or other device needed.
Portable and quick to set up
The Ray II 3D scanners need no targets and are ready for full setup in mere seconds. Additionally, the lightweight 5 kg 3D scanner including the tripod is easy to move.
Smart Auto-Removal
The Ray II features a smart auto-removal algorithm for removing moving objects that may enter or exit the scene to keep all captured data focused on exactly what is needed.
Hot-swappable Batteries
Powered by two hot-swappable batteries and another two on standby, the Ray II comes ready to scan for a full 8 hours. The batteries can be charged while you scan, and swap without any downtime.
Water and dust protection
The Ray II features IP54 (IEC 60529) water and dust protection designed to keep particles or humidity from getting into your device to protect and keep your work safe.
Perfect match for Leo
Exceptionally well-suited for use with the wireless Artec Leo, the duo can quickly capture large to massive objects with high accuracy.
An unbeatable combination of two smart, wireless scanners
Artec Ray II’s range and speed for full scenes and large objects, and the handheld Artec Leo for specific areas and angles, create the ultimate wireless combo.
All Artec 3D scanners
The long-range Ray II also integrates with all other Artec 3D scanners in seconds.
Artec Studio for professional processing
Processing your data in Artec Studio is the next step for your 3D scanning process. With our software, you have easy access to an advanced autopilot mode and the most accurate algorithms for quick and easy data processing, as well as HD Mode and high accuracy used to create the most true-to-form 3D models possible. Power up your workflow as you save time and get excellent results!
Advanced software compatibility
Upload to Artec Studio to precisely position and fit your scans with CAD primitives, then export to SOLIDWORKS or other CAD software – or for inspection, directly to Geomagic Control X for in-depth reports.
Quality inspection of large objects
Artec Ray II allows you to import your models into Artec Studio software to carry out basic quality control, and compare it to the original CAD file all in one place. For advanced operations, you can also export the model to Control X and other full package inspection software.
Perfect long-range 3D scanner
Capture complex constructions such as warehouses, factories, airports, and apartment buildings to get precise and clean 3D data about the building, such as its size, structure, facade, and more. Thanks to Ray II’s extreme accuracy and cleanliness of data, you don’t need to spend much time on processing.
Best-in-class industrial laser scanner
A large working facility, an airplane, an oil rig, or even an outdoor space — whatever industrial object or scene you need to scan, Ray II has you covered. Versatile and portable, this industrial 3D scanner is perfect for digitizing and measuring large structures with metrology-grade accuracy at any time and place — day or night, indoors or outdoors.
LiDAR 3D scanner for exact 3D measurements
Thanks to built-in LiDAR 3D scanning technology, Artec Ray II allows you to capture precise long-range 3D measurements of complex objects and shapes from up to 110-meters.
Access
With any plan in Artec Cloud, you’ll be able to view and comment on existing projects from any browser.
Project Browser
With easy viewing that you’d expect to see in any standard application or program, you’ll be able to browse through and find the project you’re looking for on any plan. The Collaboration and Processing account is required to organize folders
Project View
Within these folders, you’ll be able to view both previews and detailed information about your scans, and see who has access to these projects – it’s like any drive you’ve used before, but made with your scan data in mind.
Hover
Have you ever had a scan that was almost perfect – but ‘almost’ wasn’t good enough?
With Artec Cloud’s Hover feature, you’ll be able to single out which scan needs correction simply by mousing over the part in question and then leaving a comment with your instructions.
Collaboration
In Collaboration mode, expect no more missed messages, messy project management, or poor coordination. Here, entire projects can be worked on in one place, making it far easier to coordinate among your team.
Working together
Scans can be uploaded, comments can be left, and essential conversations can be had – you’ll even be able to share images with your co-workers for reference or inspiration. If you need to have something scanned, start a new project on Cloud, upload a photo for reference, send it to your teammate – they’ll be able to receive your task, respond to your message, and get right to work.
Save your work
With Collaboration, you won’t miss anything, either; a full history of your discussions and communication will stay right here. With all your data and previous work kept in one place, you can expect easy reference and excellent communication within your team.
Attach Images
If you or your client has a visual of what they’d like to be scanned, an image can easily be attached into your project, too. Send the project and an invitation to your client or 3D service provider, and so begins the work. Artec Cloud is now the only platform you need for communication and collaboration to take place.
Import & Share
If you are on a Collaboration or Processing plan, you’ll be able to upload and download 3D data and models. Supported files include Artec Studio data formats and popular 3D model formats such as OBJ, PLY, STL, and WRL. Uploaded data is available online immediately for viewing right away.
You can share your work with colleagues on Viewer accounts and they will be able to view and comment on it.
Processing [BETA]
With Artec Cloud, you now have easy processing with the tools you need most, right on your browser.
Key features
If you’ve gone all in with a full-access account, your processing options are similar to Artec Studio – choose between Manual and Autopilot. On a Processing account, you can process up to 20 projects per month – and since you don’t have to use up your computer memory, GPU, or CPU, you can process as many as you like at a time.
In manual mode, you’re presented with five stages of processing: Align, Prepare Scan, Make Model, Adjust Model, and Export.
Align
The alignment tool is made with ease of use in mind: Choose between manual and auto to align multiple scans according to your needs or preferences.
Prepare Scan
With fewer actions and steps, there's no need to switch between panels or different groups of algorithms, making it that much easier for new users while saving time for all. When selecting Key Frames, type the number you want, or move the slide to the desired digit.
Make Model
The Make Model process corresponds with Fusion in Artec Studio. Here, you can fuse your scans and create your 3D model before proceeding to the next stage.
Adjust Model
The final step in processing is to adjust your model. Here, you can work on texturing, mesh simplification, and removing any unnecessary noise to clean up your final model before you’re ready to share, export, or send it.
Export
Your processed 3D models can be exported with your chosen level of granularity in OBJ, STL, PLY, or VRML, while high-resolution screenshots take the form of JPG, PNG, or WEBP.
Manual Editing
Also powering up the Processing plan is manual editing. Here, you’ll have the ability to utilize the most essential tools from Artec Studio, which you can use at any stage of Processing.
Edit your data with the Eraser, Position, Transformation, Smoothen, and Mirror tools.
Erase
Remove unnecessary or unwanted data from your 3D scanning scene to create crisp, clean 3D models.
Position
Reposition or center your objects as you require during your processing. The Position tool is useful for when you work with several objects, or need to center your objects within a coordinate system.
Transform
Within Artec Cloud, you are able to change the size of your scanned objects should you need them on the same scale as one another, or larger or smaller than they appear.
Smooth
This tool is useful for when you need to smoothen scanning defects, which may at times occur when scanning tricky surfaces or hard-to-reach areas.
Mirror
Particularly useful in reverse engineering, the Mirror tool lets you flip your scan data to create a mirrored version of the objects you have scanned.
Yes. You can control the scanner remotely via the Artec Remote mobile application.
We recommend using Ray II to capture large objects such as wind turbines, ship propellers, airplanes, warehouses, and buildings.
The most distinguishing difference and advantage of Artec Ray II is that it’s much more accurate. The scanner is able to capture objects and scenes with submillimeter accuracy over long distances. This feature makes Ray II a perfect, precise solution for reverse engineering, dimensional control, forensics, and more.
Another difference is that Ray II captures much cleaner 3D data than other laser scanners. This means that you can spend significantly less time on processing and cleaning up the noise to get a final 3D model.
Another critical advantage is that data scanned with Ray II can be easily paired with the data from other Artec scanners, all-in-one software — Artec Studio. For example, a large and complex object such as an airplane or a ship can be scanned with Ray II to capture the shape and all the bigger elements, while other smaller parts can be scanned with a different Artec scanner such as Leo, Eva, or Space Spider and in even higher resolution.
Multi-resolution Smart Fusion
Artec Studio's groundbreaking Smart Fusion algorithm seamlessly combines data from various Artec 3D scanners to create highly intricate 3D meshes. You can capture extensive objects or regions using Ray II, address any missing sections with Artec Leo, and then register both scans in a single, straightforward process. The result is a blended-data model, encompassing the broader scan captured at one resolution and the finer details digitized at another.
4X faster HD Mode
Artec 3D's revolutionary HD Mode is not only the updated default setting for Artec Eva and Leo but is also subject to ongoing enhancements. It now operates at an increased speed and features a more user-friendly interface. The adjustment of point density and frame frequency is automated, and you no longer have to mess with slider adjustments. Simply select from three presets, and the algorithm takes care of the rest, simplifying the process.
2X faster Global registration
Reduce the time spent on registration of captured frames with Global Registration, an algorithm that now operates at an even faster pace, working twice as fast on average as before.
Single-step mesh optimization
Eliminate folded or dangling polygons in your mesh with Artec Studio's healing tool, which is integrated into a new mesh optimization algorithm. Easily perform mesh healing, simplification, and small object filtering with just a click of a button.
Effortless manual editing
In Artec Studio 18, you have the convenience to effortlessly maintain the fusion quality by quickly identifying and removing misaligned frames by using the alt + LMB combination. Additionally, the new Quick Transformation Tool enables you to anchor one rendered item in position while freely adjusting the position, scale, rotation, and translation of another without affecting the entire workspace.
Context-relevant quick panel
The new Quick Panel in Artec Studio is designed to offer users swift access to all the necessary features with just a click. It dynamically displays options that are directly relevant to the ongoing activities within their workspace, ensuring efficient and relevant access to tools and functions.
Boost color contrast with AI
Artec Studio is now capable of employing a neural network for the processing of raw texture frames to vastly improve color contrast, double the scan resolution, and elevate the overall quality of textures.
Scene lighting optimization
With Artec Studio 18, you can reposition light sources within a 3D scene, optimizing the rendering and display of meshes to attain the highest quality results possible.
Tolerance Check Mode
When dealing with a part that must adhere to industry-specific tolerances, simply activate Tolerance Check Mode, and your 3D map will be recalculated, highlighting areas that fall outside the designated tolerance limits.
Automate defect detection
Rapidly identify inaccuracies with the enhanced 3D Compare Map in Artec Studio. Instead of manually inspecting a model's surface, you can swiftly pinpoint its least accurate areas by instructing the algorithm to seek out maximum deviations in mesh-CAD pairs.
Updated deviation mapping
The improved 3D Compare Map also provides the flexibility to calculate the distance between mesh-CAD pairs using various methods, including along normals or from one point to another.
Optimize part thickness
Explore the locations and reasons behind variations in thickness using Thickness Mapping. This tool allows comparison of thickness to a specified reference, ensuring that narrow geometries are not susceptible to breakage.
2D section analysis
Artec Studio's Section Analysis feature enables you to divide models into segments and perform in-depth inspections, area by area. This function automatically aligns models and meshes, facilitating 2D cross-section analysis to detect any inconsistencies or discrepancies. It's designed to minimize deviations, making it an ideal tool for ensuring accuracy in quality inspections or reverse engineering.
Mesh-to-CAD auto alignment
In Artec Studio 18, the initial step of aligning mesh-CAD pairs, which used to be a manual process, has been automated, eliminating the need for user input. This streamlines the quality inspection process.
Target thickness compensation
Enhance the accuracy of measurements taken with 3D metrology tools such as the Artec Metrology Kit by compensating for the thickness of targets.
Certified for heavy duty deployment
Artec Studio has now gained PtB certification, so you can engage in industrial 3D scanning, safe in the knowledge that you’ve got a tool well-qualified for the job.
Instant deviation analysis
During the reverse engineering process, you can now seamlessly examine any deviations while extracting CAD shapes from meshes, without ever having to leave the Construct tab.
Move & offset faces
Whether you need to create a gap to accommodate deviations or adjust a part to align with the design intent, Artec Studio's move and offset tools are ideal for duplicating and modifying faces in different areas of your workspace.
Improved auto-surfacing
Since Artec Studio 17, Autosurfacing has been a popular feature with many users who re relied on it to transform polygonal meshes into models with smooth 'NURBS' surfaces. Artec Studio now introduces an updated version to help these users to further enhance the quality of geometry reconstruction.
Surface thickening tools
When dealing with the reverse engineering of intricate objects featuring non-primitive, freeform surfaces, Artec Studio now provides a solution. You can now solidify these by thickening the surface of a mesh or CAD model, and lend them greater stability in applications such as 3D printing.
Create draft angles
In Artec Studio, when 3D modeling or reverse engineering cast parts, you now have the capability to introduce a draft angle on the outer surfaces. This allows for easier extraction without causing damage to the molds.
Tools for tidying up
Most parts don't have entirely sharp edges. Artec Studio offers chamfer and fillet tools that allow you to refine models and add a level of polish, providing those finishing touches to reverse engineered parts.
Datum alignment for scan-to-CAD
As a rule of metrology, even when your scan is an impeccable digital twin of a part or object, if it isn’t properly aligned with its corresponding CAD reference model, any variances that show up can be unreliable due to misalignment.
With Datum alignment, all it takes is a few clicks to fully align your meshes and CAD models using key geometric features.
Enhanced targets support for metrology
Gain better manual control over reference objects for data registration such as circular targets, spheres, or checkerboards, if your scanning workflow requires it.
See them in 3D as part of your workspace, choose spheres or circular targets for registration, measure the distance between them, identify which are out of place or missing, and exclude them from registration. In addition, you can now import and choose multiple reference target clouds into the workspace.
Auto surfacing
Convert complex organic shapes into solid CAD models in one click with the new Auto Surface feature. Facilitate reverse engineering of complex geometries and create referential CAD surfaces for in-depth RE workflows in third-party CAD software.
Boolean operations
Modify your models with CAD entities and meshes, using industry-standard boolean operations: Union, Subtract, and Intersect. Build molds, create complex shapes, fine-tune meshes to match the design intent, and more.
Independent CAD shapes
Easily create, resize, and reposition primitive solid shapes into any part of your mesh, with no need to specify the required area for fitting. Just select the primitive you want to add, including the new cube shape (box), and that’s it.
Constraints 2.0
Artec Studio now keeps a history of the conditions and relations specified for each primitive, so you can save, edit, and refit them anytime – even outside the Construct panel. In addition, it allows you to base new constraints on the ones you imposed in previous sessions.
Mesh splitting for 3D printing
For AM professionals, preparing meshes for 3D printing is easier than ever thanks to the new Split by plane feature. This allows you to quickly and precisely break your mesh into manageable chunks, using a pre-fitted plane.
Improved Segment Brush
You can now change the size of the selected region dynamically with the Segmentation sensitivity slider. Simply mark the area you’d like to construct the CAD primitive in, and adjust the degree of expansion area with the slider.
Erase via Object selection
Your mesh editing process is now even faster thanks to the new Eraser selection mode “Object selection.” Instantly remove any unwanted elements from the scene by simply selecting separate parts of the mesh and removing them.
New Hole Filling tool
An updated Hole Filling algorithm lets you create smooth patches over any missing areas on a model. You can now choose between Flat and Smooth types of hole filling to restore the missing surfaces more precisely.
Perfect your 3D model texture for CGI
Working with photos is now even better thanks to improvements in our photo-texturing algorithm. You can now easily preview photos taken for the texture via the new photo-viewing mode and see how they fit into the texture.
Register photos in Artec Studio
Remove photos with any defects, overexposure, or ones that are poorly lit or taken at a suboptimal angle and see how they impact your final texture. With the new algorithm, images are sorted into groups: by size, camera type, or focal distance, allowing you to register them separately, and use all of them for texturing.
3D scan black, shiny, or fine areas
Artec Studio analyzes the surface of your object and automatically adjusts the sensitivity of your scanner to pick up areas that are tricky for 3D scanning. As a result, even new users can digitize black, shiny objects, or hair with ease.
CAD primitives
Speed up your workflow by performing reverse engineering operations right in Artec Studio. A full range of primitives including freeform fitting, will have you zooming along from fitting to constraining to CAD export.
Integration with SOLIDWORKS
With such an easy shift to SOLIDWORKS, your process is more streamlined than ever. In Artec Studio 16, you're never more than one click away from export to SOLIDWORKS.
Photogrammetry + scan data
Scan data and photogrammetry can now be combined in Artec Studio, making it possible to create accurate, high-res, and picture-perfect 3D models ready for use in CGI, VR/AR, and animation.
Mesh-to-CAD comparison
For a faster, more streamlined workflow, import STEP, IGES, or X_T CAD files and align your scan mesh to a CAD model without having to leave Artec Studio.
Control X integration
Create customized reports with Artec Studio by selecting the object or objects you need to inspect while Control X runs in the background. The reports most essential to your work will be generated for you.
Hassle-free export
Export your data in a wide range of formats.
Mesh: OBJ, PLY, WRL, STL, AOP, ASC, Disney PTEX, E57, XYZRGB
Point cloud (Artec Ray only): PTX, BTX, XYZ
Measurements: CSV, DXF, XML
CAD primitives: STEP, IGES, X_T
Available in 15 languages
Artec Studio is available and fully functional in 15 different languages: Chinese Simplified, Chinese Traditional, Croatian, Czech, English, French, German, Italian, Japanese, Korean, Polish, Portuguese, Russian, Spanish, and Turkish.
1.5x faster HD data reconstruction with Leo
Getting HD data for the Leo scanner is now 1.5x faster thanks to the latest update of our proprietary algorithm letting you get the necessary 3D data much quicker and focus on the design, engineering, inspection, and other tasks that matter.
Optimize reconstruction speed for your GPU
This new add-on allows you to test your computer’s graphic card and fine-tune HD Mode settings so they best fit your particular specs. Expect much faster reconstruction of HD data from your Leo or Eva than using default settings.
Exclude faulty frames from Fusion
In our updated scan processing algorithm, any incorrectly registered frames can be excluded from processing. Avoid unwanted objects and artifacts on a model, and save time on further post-processing and mesh editing.
10% faster, 30% less memory-intensive processing
Thanks to our recent Fusion algorithm update, your processing workflow is now 10% faster and requires 30% less computer RAM.
Upload meshes to Artec Cloud
Directly upload to Artec Cloud and easily share meshes (with a direct shareable link) created in Artec Studio with anyone – no AC account required. All of this can be achieved without leaving the project or switching between the two applications.
Quickly restore unsaved projects
If, for any reason, your Artec Studio project crashes, there’s no need to worry. The software will suggest that you restore it upon the next start, even if you have unsaved changes. No data gets lost!
Customize your workspace
Set up your personal Artec Studio workspace by arranging panels in a layout that works best for you. All panels can now be detached from the main window, so you can simply click and drag to any part of the workspace.
Upload multiple Artec Leo projects at once
Working with more than one Leo project? You can now import several projects scanned with Artec Leo into Artec Studio, so you can easily work and switch between them in your workspace.
