Step 1
Open the box, and dispense out some of the roll
Step 2
Close the main flap, leaving outside the dispensed portion
Step 3
Fold the dispensed portion of the role over the main flap
Step 4
Close the secondary flap over the folded dispensed role
Step 5
Gently pull the end of the roll
Step 6
Now you can easily pick the dots
Step 7
Stick them to any surface
Yes, the AESUBdots Black & White reference targets will adhere to coatings from all of the AESUB sublimating (vanishing) scanning sprays. Please note, AESUBdots Black & White are not compatible with AESUB White permanent scanning spray.
Yes, the AESUBdots Black & White have a strong adhesive which allows them to adhere to most surface including surfaces coated in scanning sprays.
AESUBdots Black & White reference targets are compatible with all types of structured light scanners, as long as the scanning software has the ability to detect them.
